Using Dexterous Hand with Franka#

https://raw.githubusercontent.com/RLinf/misc/main/pic/dexhand.jpg — Franka arm paired with a Ruiyan five-finger dexterous hand for real-world manipulation.#

Adapt the Franka real-world workflow to a Ruiyan five-finger dexterous hand. You’ll keep the same cluster and reward-model flow, then change the end effector, teleoperation input, action layout, and dex-hand configs.

Overview#

Run the Franka real-world recipe with a dexterous hand end effector.

Models

CNN policy · reward model

Algorithms

SAC/RLPD · reward-model assist

Tasks

Dexterous pick-and-place

Hardware

Franka · Ruiyan dex hand · glove

You’ll do: install Franka deps → install dex-hand deps → configure glove/hand → collect data → train.

Prerequisites: Real-World RL with Franka · Using Reward Model with Franka · Ruiyan hand driver · glove device.

Tasks#

Task	Config / entry point	Description
Collection	`realworld_collect_dexhand_data`	Collect dexterous-hand demonstrations.
Training	`realworld_dexpnp_rlpd_cnn_async`	Train a CNN policy with dex-hand actions.
Reward model	Franka reward-model workflow	Reuse the reward-model path for dexterous manipulation.

Observation and Action#

Field	Description
Observation	Franka camera frames plus dex-hand/glove state when configured.
Action	Arm action plus dexterous-hand joint or command vector.
Reward	Task completion or reward-model prediction.
Prompt	Task text from the real-world env config.

Installation#

Install the base Franka dependencies from Real-World RL with Franka, then install the dexterous-hand runtime in the workflow below.

Teleoperation#

Dexterous-hand teleoperation uses:

SpaceMouse for 6-D arm motion
a data glove for 6-D finger control
the SpaceMouse left button to enable relative glove control

Reward Model#

The reward-model path is the same as the Franka real-world reward-model workflow described in Using Reward Model with Franka.

For the dexterous-hand pick-and-place environment:

the default reward image follows env.main_image_key
main_image_key defaults to wrist_1 in examples/embodiment/config/env/realworld_dex_pnp.yaml
examples/embodiment/config/realworld_dexpnp_rlpd_cnn_async.yaml uses the reward model through the reward section

Configurations#

Use examples/embodiment/config/realworld_collect_dexhand_data.yaml for data collection. This config includes:

end_effector_type: "ruiyan_hand"
glove settings for teleoperation
data_collection for raw episode export in pickle format

Use examples/embodiment/config/realworld_dexpnp_rlpd_cnn_async.yaml for RL training. Before running, fill in:

robot_ip
target_ee_pose
policy model_path
reward model.model_path
dexterous-hand serial ports in end_effector_config and glove_config

Camera naming and crop are configured directly in override_cfg when needed. This PR does not ship any serial-specific defaults so that other projects are not affected. Without camera_names, default names follow the camera_serials list order: the first serial is wrist_1, the second is wrist_2. Serial numbers are not sorted. For example:

camera_names:
  "SERIAL1": global
  "SERIAL2": wrist_1
camera_crop_regions:
  "SERIAL1": [0.4, 0.3, 0.85, 0.7]

If you rename a camera to global, update main_image_key to global in the task YAML as well.

Run It#

On the Franka control node, install the Franka DexHand environment:
```
bash requirements/install.sh embodied --env franka-dexhand
```
This command installs the base Franka dependencies plus RLinf-dexterous-hands, which includes the Ruiyan dexterous-hand and data-glove drivers.
Put the Franka robot into programming mode, manually move it to the task target pose, then run the script on the Franka control node to acquire the target end-effector pose:
```
python -m toolkits.realworld_check.test_franka_controller \
  --robot-ip <FRANKA_IP> \
  --end-effector-type ruiyan_hand \
  --hand-port /dev/ttyUSB0
```
After the script starts, enter getpos_euler, record the Euler-angle pose it prints, and fill that value into target_ee_pose.
On the Franka control node, fill in the collection-time task configuration: robot_ip, target_ee_pose, end_effector_config, glove_config, and related settings.

On the Franka control node, collect expert demos with:

bash examples/embodiment/collect_data.sh realworld_collect_dexhand_data

On the Franka control node, collect reward raw episodes with the same entrypoint. For this pass, increase env.eval.override_cfg.success_hold_steps and use a separate log directory.
Copy the collected reward raw data from the Franka control node to the training node, or place it on shared storage in advance.
On the training node, preprocess the raw reward episodes with examples/reward/preprocess_reward_dataset.py as described in Using Reward Model with Franka.
On the training node, train the reward model with examples/reward/run_reward_training.sh.
Before the final RL run, follow the cluster setup section in Real-World RL with Franka to start a two-node Ray cluster with the training node as head and the Franka control node as worker.
On the training node, launch RL with:

bash examples/embodiment/run_realworld_async.sh realworld_dexpnp_rlpd_cnn_async
